– VoIP Audio Interface Module
[ec_addtocart productid=”270″]
Description:
- IP enable any Uni-directional or Bi-directional simplex audio device.
- Proven support for Tech Works ICA-202D Amplifier or Harding DXL Digital Communication Controller
Features:
- Web browser based configuration and status page.
- Audio Stream Recording support.
- Line level audio input and output.
- Sinking outputs to indicate Audio Connected, Audio Direction, and Auxiliary Hi-wattage Page Mode states.
- Simple two connector design, a Network RJ-45 connector and a multi-pin Audio / Control / Power connector for easy installation and maintenance.
- Onboard Power, Health Status, Diagnostics and Network link LEDs.
- Built-In Sonic IP address support.
- Wide power supply voltage range – 9VDC to 24VDC.
- Draws between 500mA to 1A.
- Designed to be mounted in TE 3TK2 / 3TK2D snap track.
- Board material: Industry standard FR4 94-V0 fire resistant self extinguishing fiberglass epoxy.
- Dimensions X:3.25 inches, Y: 3.95 inches
Note:
- Requires a VT-VAMRS unit for Audio Stream Recording.
Cut Sheet:
